SANY SY750

INDUSTRY LEADING 5-YEAR WARRANTY

Built to endure the hardest working environments, SANY’s large SY750H excavator has been designed for mass excavation work with a dig depth of 25ft and bucket breakout force of 92,171 Ibf. When it comes to equipment, this machine is in the top class. Everything you would expect from an excavator in the 78–tonne class is included on-board as standard.

  • Powerful Stage V CUMMINS engine
  • Smooth operation from ergonomically designed ROPS/FOPS operators cab
  • 5 year warranty for complete peace of mind

Download Brochure Enquire Now Book a Demo

BENEFITS & FEATURES

With its even balance of power and precision, the SANY SY750H is just the right workhorse for cost-oriented use on the job site.

  • Heavy-duty undercarriage and solid boom provide an exemplary level of stability
  • Powerful Stage V CUMMINS engine with selectable power modes and smart hydraulic control system to maximise on fuel economy
  • 1-way and 2-way primary auxiliary and 2-way secondary auxiliary circuits with dedicated auxiliary rotate pump
  • 100% steel bodywork for maximum protection and reduced cost of ownership
  • Hammer, bi-directional and rotate pipework with proportional controls enabling maximum versatility whatever the application

The SY750H includes a combination of safety features that work together to minimise risks to those people in and around the machine.

  • ROPS/FOPS certified cab for safe operation
  • Rear and side view camera for panoramic visibility
  • Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety
  • LED work lights positioned on the boom, front and side of the cab for maximum visibility in low light conditions

The ergonomically designed operators cab of the SY750H ensures both comfort, convenience and maximum productivity.

  • Deluxe, ergonomic and fully adjustable, heated operator’s seat
  • Clear instrumentation and large 10.4″ high resolution colour display
  • Adjustable ventilation, heating and automatic climate control system
  • Integrated cooling box and large amount of storage space
  • Radio, USB charging port and Bluetooth connectivity
  • Easy access to all maintenance points
  • Low maintenance requirements and longer service intervals
  • Ergonomic handrails and anti-slip tread surfaces allow safe access to the maintenance platform
  • Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category
  • 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)

Technical Specification

  • Transport Length = 12879 mm
  • Transport Width = 3499 mm
  • Transport Height = 4981 mm
  • Upper Structure Width (with step) = 4479 mm
  • Cab Height = 3795 mm
  • Track Width (standard shoe) = 650 mm
  • Track Gauge = 3380 mm
  • Ground Clearance = 892 mm
  • Tail swing Radius = 4175 mm
  • Track Length on Ground = 4770 mm
  • Track Length = 5986 mm

  • Maximum Digging Height = 11020 mm
  • Maximum Dumping Height = 7170 mm
  • Maximum Digging Depth = 7580 mm
  • Maximum Vertical Wall Digging Depth = 4890 mm
  • Maximum Reach at Ground Level = 12100 mm
  • Minimum Swing Radius = 5390 mm
  • Bucket Breakout Force (ISO) = 410.0 kN
  • Stick (Arm) Digging Force (ISO) = 354.0 kN

  • Operating weight = 78,500 kg

  • Model = Cummins X15
  • Gross Power = 391 kW

  • Operating Flow (maximum) 2@504 L/min = 1008 L/min
  • Operating Pressure (maximum) = 34.3 MPa
  • Travel Pressure = 34.3 Mpa
  • Slew Pressure = 28.5 Mpa
  • Pilot Pressure = 3.9 Mpa

  • Tank = 940 l
  • Engine coolant = 75 l
  • Engine oil = 39 l
  • Hydraulic tank = 680 l
  • DEF tank = 100 l
