SANY SY215C

With the SANY SY215C crawler excavator, you get more done. This machine is a real all-rounder and a specialist in every discipline, from quick loading to precise digging and powerful demolition work. What sets it apart is its ability to control its tremendous power with great precision – for maximum productivity and therefore a fast return on investment.

  • Stage V CUMMINS engine and finely tuned Kawasaki hydraulic system
  • Extremely powerful and offers outstanding driver comfort
  • 5 year warranty for complete peace of mind

Download Brochure Enquire Now Book a Demo

BENEFITS & FEATURES

With the SANY SY215C crawler excavator you can expect the ultimate in performance, versatility on site and enhanced efficiency thanks to the smart hydraulic control system.

  • Heavy-duty undercarriage and solid boom provide an exemplary level of stability
  • Stage V CUMMINS engine and smart hydraulic control system to maximise on fuel economy
  • Hammer, bi-directional and rotate pipework with proportional controls enabling maximum versatility whatever the application
  • 100% steel bodywork for maximum protection and reduced cost of ownership

The combination of safety features for the SY215C provides a safe working environment for both the operator and bystanders.

  • ROPS/FOPS certified cab for safe operation
  • Rear and side view camera provide optimal visibility for increased on site safety
  • Travel alarm, green seat belt and rotating warning beacon to increase visibility, attract attention and ensure safety
  • LED work lights for maximum visibility in low light conditions

The SY215C has been designed for your operators comfort and ease of use.

  • Ergonomic and fully adjustable, heated operator’s seat
  • Clear instrumentation and large high resolution colour display
  • Adjustable ventilation, heating and automatic climate control system
  • Integrated cooling box and large amount of storage space
  • Radio and speaker
  • Easy access to all maintenance points
  • Low maintenance requirements and longer service intervals
  • Ergonomic handrails allow safe access to the maintenance platform
  • Registered and protected with the CESAR Datatag Scheme (the premier initiative against equipment theft) and CESAR ECV for quick and easy verification of emissions category
  • 5-year/5000 hour warranty as standard for complete peace of mind (Terms and Conditions apply)

Technical Specification

  • Transport length = 9,635 mm
  • Transport width = 3,080 mm
  • Transport height = 3,090 mm
  • Upper structure carriage width = 2,753 mm
  • Height over cabin/ROPS = 2,960 mm
  • Height of boom – transport = 3,370 mm
  • Overall length of crawler = 4,450 mm
  • Track gauge = 2,380 mm
  • Track height = 923 mm
  • Track pads width = Standard 700mm. Optional 600mm / 800mm
  • Minimum ground clearance = 468 mm
  • Counterweight clearance = 1,090 mm
  • Engine cover height = 2,630 mm
  • Tail swing radius = 2,950 mm
  • Centre distance of tumblers = 2,380 mm
  • Ground pressure = 50 KPa

  • Operating weight = 24,000 kg

  • Manufacturer = Cummins
  • Model = Cummins QSB 6.7 – 6 cylinder
  • Rated power = 129 kW
  • Max. torque = 1472 Nm
  • Displacement = 6.7 l
  • Exhaust emissions = Stage V
  • Batteries = 24 v

  • Max. Oil flow = 2x 241 l/min

  • Implement circuit = 34.3MPa
  • Power boost = 37.3 MPa
  • Swing circuit = 27.5 MPa
  • Travel circuit = 34.3 MPa
  • Pilot pressure = 3.9 MPa

  • Fuel tank = 370 l
  • Engine coolant = 27.6 l
  • Engine oil = 27 l
  • Drive (per side) = 5.5 l
  • Hydraulic oil tank = 200 l
  • AdBlue = 45 l

  • Swing speed = 11 rpm
  • Travel speed (Low/High) = 3.3/5.4 km/h
  • Max. travel force = 191 kN
  • Gradeability = 70%*(35°)
  • Bucket digging force ISO = 143 kN
  • Arm digging force ISO = 115 kN
  • Boom length = 5,700 mm
  • Arm length = 2,925 mm
  • Bottom rollers = 9
  • Top rollers = 2
  • Ground pressure = 50 KPa

  • Max. digging reach = 9,745 mm
  • Max. digging depth = 6,450 mm
  • Max. digging Height = 9,470 mm
  • Max. dumping height = 6,735 mm

  • Heavy duty belly plates = Standard equipment
  • Bucket ram guard = Standard equipment
  • Stick ram guard = Standard equipment
  • Boom hoist guards = Standard equipment
  • Bolt on side impact protection (3 piece) = Standard equipment
  • 8 pre-settings for hydraulic attachments = Standard equipment
  • FOG guard bolt on cab protection (Level 2) = Standard equipment
