Pezzolato S7000

S 7000 hammer chopper is a medium/small machine. It is equipped with a rotor with 64 articulated hammers disposed in four rows and a counter-hammers system to adjust the chopping size.

The material to be chopped is introduced (either manually or mechanically) in the large hopper equipped with a closed chains conveying belt with prawls on the bottom and an upper hydraulic dosing roller which crushes and adjusts the passage of the material under the action of the hammers.

These features make this machine ideal for third-party park and garden maintenance operators, for small compost stations and for small ecological areas.

Minimum tractor power

50 hp / 37 kW

hp/kW

Diesel engine power

75 hp / 56 kW

hp/kW

Electric motor power

37 kW / 50 hp

kW/hp

Hopper dimensions

3100 x 1550 mm / 10' 2.05'' x 5' 1.02''

mm/ft

Width of measuring roller

630 mm / 24.80''

mm/in

Dosing roller max opening

200 mm / 7.87''

mm/in

Chopping chamber diameter

530 mm / 20.87''

mm/in

Hooked steel feeding conveyor width

2150 x 630 mm / 7' 0.64'' x 24.80''

mm/in

Number of hammers

64 - 96

Hammers thickness

6-12 mm / 0.236-0.472''

mm/in

Hammers peripheral speed

65

m/s

Hourly throughoutput

20

m³/h

Overall dimensions

5700 x 1920 x 2840 mm / 18' 8.41'' x 6' 3.59'' x 9' 3.81''

mm/ft

Weight PTO machine (std model)

2400 kg / 5291 lbs

kg/lbs
